Transmission | Gen 2 Automatic PVT H/L/N/R/P; Shaft |
Chain Type | 2.276:1 |
Clutch | Multiple-disc clutch in oil bath |
Gearbox | 6-speed |
Gear Ratios 1st | 2.769 : 1 |
Gear Ratios 2nd | 1.882 : 1 |
Gear Ratios 3rd | 1.500 : 1 |
Gear Ratios 4th | 1.273 : 1 |
Gear Ratios 5th | 1.125 : 1 |
Gear Ratios 6th | 0.966 : 1 |
Transmission Type | Chain (final drive) |
Front Suspension | Dual A-Arm |
Rear Suspension | Dual A-Arm IRS |
Front Shocks | Twin tube gas-charged shocks |
Rear Shocks | Twin tube gas-charged shocks |
Front Travel | 17.6 in (447 mm) |
Rear Travel | 20.1 in (510 mm) |
Front Braking System | Single disc. Single disc with twin-piston caliper. Optional ABS. |
Rear Braking System | Single disc. Single disc with single-piston caliper. Optional ABS. |
Parking Brake | Park In-Transmission |
Wheels | Aluminum |
Front Tire | 29 x 9-14; PRO ARMOR X-TERRAIN | Tire Ply Rating: 8-Ply Rated |
Rear Tire | 29 x 11-14; PRO ARMOR X-TERRAIN | Tire Ply Rating: 8-Ply Rated |
Front Wheel | Cast 8-Spoke 16" x 3.5" |
Rear Wheel | Cast 8-Spoke 16" x 3.5" |
Wheelbase | 81 in (2,060 mm) |
Ground Clearance | 14 in (360 mm) |
Bed Box Dimensions | 36.75 x 54.25 x 12.5 in (93 x 138 x 32 cm) |
Seat Height | 28.9 in |
Rake / Trail | 26.3° / 4" |
Overall Vehicle Size | 30.9" w x 88.6" l x 43.3" h |
Lean Angle (Left) | 31 |
Lean Angle (Right) | 31 |
Hitch Type | Standard 2 in (5 cm) Receiver |
Hitch Capacity | 2,500 lb (1,134 kg) |
Cargo System | Lock & Ride |
Payload Capacity | 680 lbs (1,500 kg) |
Fuel Capacity | 11.5 gal (43.5 L) |
Box Capacity | 1000 lbs (454 kg) |
Storage Capacity | 16.2 gal (61.3 L) |
Towing Capacity | 1,134 lbs (2,500 kg) |
Rack Capacity (Front) | 120 lb (54.4 kg) |
Rack Capacity (Rear) | 240 lb (109 kg) |
Cargo Capacity | 454 lbs (1,000 kg) |
Bed Capacity | 1000 pounds for 49-state models |
Rack Capacity | Front: 120 lb (54.4 kg) / Rear: 240 lb (109 kg) |
Seating Capacity | 0 |
Dry Weight | 388 lbs |
Gauges | 4.5 in. wide digital display |
Magneto | 650 W |
Audio System | Includes 2 Standard 50 watt fairing speakers, 100 watts total. |
Steering | Tilt: Standard |
Features | Water Fording Height: Equal to the Floorboards | Other Standard: Front Bumper with Integrated Winch, Plow & LED Mounts, Premium Cut & Sew Seats with Contoured Seatbacks and Embroidered Polaris Branding, Polaris HD 4500 lb Synthetic Rope Winch with Autostop and Wireless Remote, Factory-Installed Poly Sport Roof, Single Latch Cab Nets, Polaris Pulse Electrical System (6 position), 12V Accessory Outlet, Battery Trickle-Charging Outlet, USB Outlet |
Lighting | Dual LED Headlights, 1250lm Low Beam, 2300lm High Beam, Dual LED Tail Lights |
Instrumentation | Dual-sweep Analog Dials w/ 4" LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder, DC Outlet, USB Charge Port, Automatic Speed Limiting in 2 mph increments starting at 16 mph to max speed. |
Warranty | 12 Month Limited Warranty |
Cage Type | Profiled cage, ROPS approved |
Handlebars | Neken, aluminium 28/22 mm |
