Transmission | Automatic PVT P/R/N/L/H In-line Shifting |
Gearbox | 6-speed |
Chain Type | #520 Chain, 10T/41T |
Clutch | Multi-plate with diaphragm spring in oil bath |
Transmission Type | Chain (final drive) |
Gear Ratios 1st | 9.403 : 1 |
Gear Ratios 2nd | 6.411 : 1 |
Gear Ratios 3rd | 4.763 : 1 |
Gear Ratios 4th | 3.796 : 1 |
Gear Ratios 5th | 3.243 : 1 |
Gear Ratios 6th | 2.789 : 1 |
Front Suspension | Independent Double Wishbone |
Rear Suspension | Independent Double Wishbone |
Front Travel | 12.2 in (310 mm) |
Rear Travel | 11.8 in (300 mm) |
Front Shocks | SHOWA HPG piggyback 2.5 (dual-speed Compression, Dual-rate spring) |
Rear Shocks | SHOWA HPG piggyback 2.5 (dual-speed Compression, Dual-rate spring) |
Front Braking System | Dual Hydraulic Disc |
Rear Braking System | Dual Hydraulic Disc |
Parking Brake | Park In-Transmission / Lockable Hand Lever |
Front Tire | 26 x 8 CST |
Rear Tire | 26 x 10 CST |
Wheels | 14 in. (35.6 cm) Aluminum |
Front Wheel | Machine Highlighted Cast Black 19 in x 3.5 in |
Rear Wheel | Machine Highlighted Cast Black 16 in x 5 in |
Overall Vehicle Size | 64" w x 133.3" l x 79.5" h |
Rake / Trail | 26° / 7" |
Wheelbase | 57 in (1,448 mm) |
Seat Height | 35.8 in (908 mm) |
Ground Clearance | 11.2 in (285 mm) |
Lean Angle (Left) | 28.5 |
Lean Angle (Right) | 28.5 |
Bed Box Dimensions | 36.75 x 54.25 x 12.5 in (93 x 138 x 32 cm) |
Fuel Capacity | 5.25 gal (19.9 L) |
Seating Capacity | 0 |
Hitch Type | Standard 1.25 in (3.2 cm) Receiver |
Hitch Capacity | 1,500 lb (680 kg) |
Cargo System | 4 Gal (15 L) Front Dry Storage 2 Gal (8 L) Rear Storage |
Payload Capacity | 261 lbs (575 kg) |
Rack Capacity (Front) | 120 lb (55 kg) |
Rack Capacity (Rear) | 240 lb (110 kg) |
Towing Capacity | 830 lbs (1,830 kg) |
Storage Capacity | 2.5 gal (9.4 L) |
Rack Capacity | 200 lb (91 kg) with LinQ quick-attach |
Box Capacity | 1000 lbs (454 kg) |
Cargo Capacity | 199 lbs (439 kg) |
Bed Capacity | 1000 pounds |
Dry Weight | 804 lbs (365 kg) |
Gauges | 4.5 in. digital display with keypad |
Audio System | Includes 2 Standard 50 watt fairing speakers, 100 watts total. |
Magneto | 850-W |
Warranty | 36 / Limited |
Features | Other Standard: Painted Plastics |
Lighting | 50w High Beam, Dual 50w Low Beam Headlights |
Instrumentation | All Digital Gauge, Speedometer, Odometer, Tachometer, 2 Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, AWD Indicator, Volt Meter, Coolant Temperature, Hi-Temp Light, Clock, DC Outlet |
Steering | Power: High torque Tri-Mode Dynamic Power Steering (DPS) |
Cage Type | Dual-phase 980 steel |
Handlebars | Aluminum |
Headlight Type | LED |
