Chain Type | #520 Chain; 16T/45T |
Clutch | Wet, Multi-Plate, Assist |
Gear Ratios 1st | 9.403 : 1 |
Gear Ratios 2nd | 6.411 : 1 |
Gear Ratios 3rd | 4.763 : 1 |
Gear Ratios 4th | 3.796 : 1 |
Gear Ratios 5th | 3.243 : 1 |
Gear Ratios 6th | 2.789 : 1 |
Transmission | Automatic PVT P/R/N/L/H In-line Shifting |
Gearbox | 6-speed |
Transmission Type | Chain (final drive) |
Front Suspension | Sealed Arched Dual A-Arm |
Rear Suspension | Sealed Dual A-Arm, IRS |
Front Travel | 5.1 in (130 mm) |
Rear Travel | 4.5 in (114 mm) |
Front Shocks | Walker Evans Velocity Series Shocks |
Rear Shocks | Walker Evans Velocity Series Shocks |
Front Braking System | Single Lever 3-Wheel Hydraulic Disc with Hydraulic Rear Foot Brake |
Rear Braking System | Single Lever 3-Wheel Hydraulic Disc with Hydraulic Rear Foot Brake |
Parking Brake | Park In-Transmission / Lockable Hand Lever |
Front Wheel | 10-Spoke Cast Black 19 in x 3.5 in |
Rear Wheel | 10-Spoke Cast Black 16 in x 5 in |
Front Tire | 26 x 8-14; DURO |
Rear Tire | 26 x 10-14; DURO |
Wheels | 14 in. (35.6 cm) Aluminum |
Overall Vehicle Size | 39" w x 98.4" l x 53" h |
Rake / Trail | 25° / 6" |
Wheelbase | 50.5 in (1,283 mm) |
Seat Height | 33.2 in (845 mm) |
Ground Clearance | 11.5 in (290 mm) |
Lean Angle (Left) | 31 |
Lean Angle (Right) | 31 |
Bed Box Dimensions | 27.5 x 43.1 x 11.6 in (69.8 x 109 x 29.5 cm) |
Fuel Capacity | 4.5 gal (17 L) |
Hitch Type | Standard 1.25 in (3.2 cm) Receiver |
Hitch Capacity | 1,350 lb (612 kg) |
Cargo System | Lock & Ride Compatible 5 Gal (18.9L) Front Dry Storage |
Payload Capacity | 220 lbs (485 kg) |
Box Capacity | 1,500 lbs. (680 kg) |
Seating Capacity | 0 |
Bed Capacity | 600 lb (272 kg) Rear Dumping Box |
Cargo Capacity | 454 lbs (1,000 kg) |
Storage Capacity | 9 gal (34 L) |
Towing Capacity | 830 lbs (1,830 kg) |
Rack Capacity | Front: 120 lb (54.4 kg) / Rear: 240 lb (109 kg) |
Rack Capacity (Front) | 90 lb (40.8 kg) |
Rack Capacity (Rear) | 180 lb (81.6 kg) |
Dry Weight | 873 lbs (396 kg) |
Gauges | Fairing-Mounted Instrument Cluster with Analog Speedometer and Tachometer; Fuel Gauge, Range, Odometer and Current Gear |
Magneto | 850-W |
Features | Other Standard: Front Trail Bumper, 2,500 lb. Polaris HD Winch, 12 Volt Power Plug, Pre-Wired for Hand & Thumb Warmers, In Pod Battery Charger, Painted Plastics, Front and Rear A-Arm Guards |
Lighting | LED POD, LED Bumper Lights, Dual LED Brake lights/Taillights |
Warranty | 2 years |
Steering | Standard Tilt & Telescoping |
Instrumentation | All Digital Gauge, Speedometer, Odometer, Tachometer, Two Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, AWD Indicator, Volt Meter, Coolant Temperature, Hi-Temp Light |
Cage Type | Dual-phase 980 steel |
