Transmission | Automatic PVT P/R/N/L/H In-line Shifting |
Transmission Type | Chain (final drive) |
Clutch | PASC slipper clutch, hydraulically actuated |
Gearbox | 6-speed |
Chain Type | 2.2 : 1 |
Gear Ratios 1st | 9.403 : 1 |
Gear Ratios 2nd | 6.411 : 1 |
Gear Ratios 3rd | 4.763 : 1 |
Gear Ratios 4th | 3.796 : 1 |
Gear Ratios 5th | 3.243 : 1 |
Gear Ratios 6th | 2.789 : 1 |
Front Suspension | Independent Double Wishbone |
Rear Suspension | Independent Double Wishbone |
Front Shocks | KYB HPG with preload ajdustment |
Rear Shocks | KYB HPG with remote reservoir 4-position compression adjustable damping and preload adjustment |
Front Travel | 8.7 in (220 mm) |
Rear Travel | 8.7 in (220 mm) |
Front Braking System | Dual Hydraulic Disc |
Rear Braking System | Dual Hydraulic Disc |
Parking Brake | Park In-Transmission / Lockable Hand Lever |
Wheels | 12 in. (30.5 cm) Steel |
Front Tire | 25x8-12 P373; 6 PLY |
Rear Tire | 25x10-12 P373; 6 PLY |
Front Wheel | 5-spoke, Deep Black, machined and tinted, 16 x 4.5 in. (406 x 114 mm) |
Rear Wheel | 5-spoke, Deep Black, machined and tinted, 16 x 6.5 in. (406 x 165 mm) |
Wheelbase | 50.5 in (1,283 mm) |
Ground Clearance | 11.5 in (290 mm) |
Bed Box Dimensions | 36.75 x 54.25 x 12.5 in (93.3 x 137.8 x 31.75 cm) |
Overall Vehicle Size | 64" w x 122" l x 77.2" h |
Seat Height | 33.2 in (845 mm) |
Rake / Trail | 26° / 4" |
Lean Angle (Left) | 31 |
Lean Angle (Right) | 31 |
Seating Capacity | 0 |
Storage Capacity | 1.85 gal (7 L) |
Towing Capacity | 1,134 lbs (2,500 kg) |
Fuel Capacity | 4.5 gal (17 L) |
Rack Capacity | Front: 120 lb (54.4 kg) / Rear: 240 lb (109 kg) |
Hitch Type | Standard 1.25 in (3.2 cm) Receiver |
Hitch Capacity | 1,350 lb (612 kg) |
Cargo System | Lock & Ride Compatible 5 Gal (18.9L) Front Dry Storage |
Payload Capacity | 220 lbs (485 kg) |
Box Capacity | 1,000 lbs (453.6 kg) |
Cargo Capacity | 199 lbs (438 kg) |
Rack Capacity (Front) | 90 lb (40.8 kg) |
Rack Capacity (Rear) | 180 lb (81.6 kg) |
Bed Capacity | 1000 pounds for 49-state models |
Dry Weight | 1,660.4 lbs |
Gauges | 4.5 in. wide digital display |
Magneto | 650 W |
Audio System | Upgraded PowerBand 2.0 Audio package Includes: 2 - 100 watt fairing speakers, 2 - 100 watt saddlebag speakers. 400 watts total. |
Steering | Power: Dynamic Power Steering (DPS) |
Cage Type | Profiled cage, ROPS approved |
Features | Other Standard: Front Trail Bumper, Front Rack Extender, Rear Rack Extender, 12 Volt Power Plug, Pre-Wired for Hand & Thumb Warmers, In Pod Battery Charger, Winch Mount Included, Front A-Arm Guards |
Lighting | Halogen Pod & Bumper Lights, Triple 50w High Beams, Dual 50w Low Beams, Dual LED Brake Light/Taillight |
Instrumentation | All Digital Gauge, Speedometer, Odometer, Tachometer, Two Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, AWD Indicator, Volt Meter, Coolant Temperature, Hi-Temp Light |
Warranty | 36 / Limited |
Handlebars | Neken, aluminium 28/22 mm |
Headlight Type | LED |
