Transmission | Gen 2 Automatic PVT H/L/N/R/P; Shaft |
Gearbox | 6-speed |
Clutch | Wet, Multi-Plate, Assist |
Chain Type | 2.2 : 1 |
Gear Ratios 1st | 9.403 : 1 |
Gear Ratios 2nd | 6.411 : 1 |
Gear Ratios 3rd | 4.763 : 1 |
Gear Ratios 4th | 3.796 : 1 |
Gear Ratios 5th | 3.243 : 1 |
Gear Ratios 6th | 2.789 : 1 |
Transmission Type | Six-speed manual with slipper clutch |
Front Suspension | Dual A-Arm |
Rear Suspension | Dual A-Arm IRS |
Front Shocks | FOX 2.0 Podium QS3 with Position Sensitive Spiral technology |
Rear Shocks | FOX 2.5 Podium QS3 with Position Sensitive Spiral technology |
Front Travel | 12.2 in (310 mm) |
Rear Travel | 12.3 in (312 mm) |
Front Braking System | 4-Wheel Hydraulic Disc with Dual-Bore Front Calipers |
Rear Braking System | 4-Wheel Hydraulic Disc with Dual-Bore Front Calipers |
Parking Brake | Park In-Transmission |
Front Wheel | Highlight Machine Tour 17 in x 3.5 in |
Rear Wheel | Highlight Machine Tour 16 in x 5 in |
Front Tire | 29 x 9-14; PRO ARMOR X-TERRAIN | Tire Ply Rating:8-Ply Rated |
Rear Tire | 29 x 11-14; PRO ARMOR X-TERRAIN | Tire Ply Rating:8-Ply Rated |
Wheels | Aluminum |
Wheelbase | 113 in (2,870 mm) |
Seat Height | 26.5 in (673 mm) |
Ground Clearance | 14 in (360 mm) |
Overall Vehicle Size | 40.2" w x 104.6" l x 55.7" h |
Rake / Trail | 25° / 5.9" |
Bed Box Dimensions | 36.75 x 54.25 x 12.5 in (93 x 138 x 32 cm) |
Lean Angle (Left) | 31 |
Lean Angle (Right) | 31 |
Cargo Capacity | 187 lbs (412 kg) |
Storage Capacity | 1.85 gal (7 L) |
Towing Capacity | 182 lbs (400 kg) |
Fuel Capacity | 11.5 gal (43.5 L) |
Seating Capacity | 2 |
Bed Capacity | 1,500 lbs. (680 kg) |
Rack Capacity | 150 lb (68 kg) with LinQ quick-attach |
Rack Capacity (Front) | 90 lb (40.8 kg) |
Rack Capacity (Rear) | 1,250 lb. (567 kg) |
Payload Capacity | 522 lbs (1,150 kg) |
Hitch Type | Standard 2 in (5 cm) Receiver |
Hitch Capacity | 2,500 lb (1,134 kg) |
Cargo System | Lock & Ride |
Box Capacity | 1000 lbs (454 kg) |
Dry Weight | 2,387 lbs (1,083 kg) |
Gauges | Fairing-mounted instrument cluster featuring analog speedometer and tachometer with fuel gauge, range, odometer and current gear. 15 LED telltale indicators; cruise control enabled, cruise control set, neutral, high beam, turn signal, ABS, check engine, low tire pressure, battery, low fuel, security system, low engine oil pressure and MPH or km/h unit designation. |
Magneto | 850-W |
Audio System | Includes 4 Standard 50 watt speakers. 2 in the fairing, 2 in the trunk. 200 watts total. |
Features | Audio System: JBL Trail Pro 2000 | Water Fording Height: Equal to the Floorboards | Other Standard: Premium Pro-Shield Cab; Doors with Power Windows; Tip-Out Glass Windshield with Wiper; Rear Glass Panel; Factory-Installed Heat, AC, Defrost; Rearview Mirror; Premium Steering Wheel and Interior Accents; NorthStar Tailgate Badge; Front Bumper with Integrated Winch, Plow & LED Mounts; Premium Cut & Sew Seats with Contoured Seatbacks and Embroidered Polaris Branding; Polaris HD 4500 lb Synthetic Rope Winch with Autostop and Wireless Remote; Polaris PulseElectrical System (6-Position) Underhood Busbar and 6-Position Roof Busbar; 12V Accessory Outlet; Battery Trickle-Charging Outlet; USB Outlet |
Instrumentation | 7" Display Powered by RIDE COMMAND: Plow Mode, Group Ride, GPS Navigation, Bluetooth, AM/FM Radio; Dual-sweep Analog Dials w/ 4" LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder, 2 DC Outlets, USB Charge Port, Automatic Speed Limiting in 2 mph increments starting at 16 mph to max speed. |
Warranty | Factory: 2 Years, Unlimited Miles |
Lighting | Dual LED Headlights, 1250lm Low Beam, 2300lm High Beam, Dual LED Tail Lights |
Steering | Tilt: Standard |
Cage Type | Dual-phase 980 steel |
Handlebars | Ergonomy and controls sized for 6 years old and up |
