Drivetrain
| Gearbox | 6-speed |
| Chain Type | 520 X-Ring |
| Clutch | Automatic |
| Gear Ratios 1st | 10.169:1 |
| Gear Ratios 2nd | 6.933:1 |
| Gear Ratios 3rd | 5.151:1 |
| Gear Ratios 4th | 4.105:1 |
| Gear Ratios 5th | 3.508:1 |
| Gear Ratios 6th | 3.017:1 |
| Transmission | Automatic PVT H/L/N/R/P; Shaft |
| Transmission Type | Six-speed automatic Dual-Clutch Transmission (DCT) |
Suspension
| Front Travel | 7.9 in (201 mm) |
| Rear Travel | 9.1 in (231 mm) |
| Front Suspension | Independent Double Wishbone |
| Rear Suspension | Independent Double Wishbone |
| Front Shocks | FOX 1.5 PODIUM QS3 |
| Rear Shocks | FOX 1.5 PODIUM QS3 |
Brakes
| Front Braking System | Dual Hydraulic Disc |
| Rear Braking System | Hydraulic Disc |
| Parking Brake | Park In-Transmission |
Tires
| Front Tire | 25/8-12 |
| Rear Tire | 25/10-12 |
| Front Wheel | 10-Spoke Machined Cast 19" x 3.5" |
| Rear Wheel | 10-Spoke Machined Cast 16" x 5" |
| Wheels | Aluminum |
Dimensions
| Rake / Trail | 27° / 4" |
| Wheelbase | 76.8 in (1,951 mm) |
| Seat Height | 37.8 in (960 mm) |
| Ground Clearance | 10.8 in (274 mm) |
| Overall Vehicle Size | 59.9" w x 114.8" l x 77.6" h |
| Lean Angle (Left) | 31 |
| Lean Angle (Right) | 31 |
| Bed Box Dimensions | 33.3 x 48.7 x 12.3 in (84.6 x 123.7 x 31.2 cm) |
Capacities
| Fuel Capacity | 8.1 gal (30.7 L) |
| Payload Capacity | 318 lbs (700 kg) |
| Box Capacity | 500 lb (226.8 kg) |
| Storage Capacity | 10.6 gal (40 L) |
| Towing Capacity | 680 lbs (1,500 kg) |
| Rack Capacity (Front) | 120 lb (54.4 kg) |
| Rack Capacity (Rear) | 500 lb. (226.8 kg) |
| Hitch Type | Standard 2 in (5 cm) Receiver |
| Cargo System | Lock & Ride |
| Cargo Capacity | 136 lbs (300 kg) |
| Rack Capacity | 150 lb (68 kg) with LinQ quick-attach |
| Hitch Capacity | 1,500 lb (680 kg) |
| Seating Capacity | 0 |
| Bed Capacity | 900 pounds |
Weights
| Dry Weight | 1,502 lbs (681 kg) |
Electronics
| Gauges | 7.6 in. wide digital display |
| Audio System | Includes 4 Standard 50 watt speakers. 2 in the fairing, 2 in the trunk. 200 watts total. |
| Magneto | 850-W |
Lights & Safety
| Warranty | 12 / Limited |
| Features | Gas Assist Dump Box, Single Latch Tailgate, Rear-mounted Fiberglass Insulated Exhaust System, Standard In-dash SAE Charge Port, 575 CCA Battery, 660W Charging System (Stator), 20.25 Gal. Onboard Storage with Enclosed Dash Bins and Integrated Cell-phone Holder, Sealed Suspension Bushings and Wheel Bearings, Full Coverage Steel Front Bumper with Integrated Winch and Plow Mounts, Full Coverage Skid Plate, Premium Body Panels, Premium Cut & Sew Seats, Polaris Pulse Electrical System (3 position), Polaris HD 3,500 Lb. Synthetic Rope Winch with Autostop and In-Dash Switch, Premium Pro-Shield Cab, Doors with Crank Windows, Integrated Door Storage, Fixed Glass Windshield with Wiper and Washer Fluid, Rear Glass Panel, Factory Installed Heat with Defrost, Upper and Lower Dash Vents and Variable Fan Speed, USB Charging Port, Front Stabilizer Bar, Rear Wheel Liners, NorthStar Badging |
| Lighting | High/Low Beam LED Headlights LED Taillamps |
| Instrumentation | 4" LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder, DC Outlet |
| Steering | Head Angle: 63.9 |
| Cage Type | Dual-phase 980 steel |
| Handlebars | Aluminum |
Frequently asked questions about 2025 Honda Pioneer 700 Deluxe
What type of fuel does a 2025 Honda Pioneer 700 Deluxe use?
A 2025 Honda Pioneer 700 Deluxe uses Gasoline.
What is the 2025 Honda Pioneer 700 Deluxe fuel capacity?
A 2025 Honda Pioneer 700 Deluxe has the fuel capacity of 8 gallons.
What type of engine does the 2025 Honda Pioneer 700 Deluxe have?
The 2025 Honda Pioneer 700 Deluxe is equipped with a 4-stroke engine.
How is the 2025 Honda Pioneer 700 Deluxe cooled?
The 2025 Honda Pioneer 700 Deluxe is cooled by Liquid.
What type of fuel system does the 2025 Honda Pioneer 700 Deluxe have?
The 2025 Honda Pioneer 700 Deluxe is equipped with a Fuel Injection fuel system.
What type of starter does the 2025 Honda Pioneer 700 Deluxe have?
The 2025 Honda Pioneer 700 Deluxe is equipped with a Electric starter.
What is the 2025 Honda Pioneer 700 Deluxe compression ratio?
The 2025 Honda Pioneer 700 Deluxe has a compression ratio of 9.2:1.
What type of front brakes does the 2025 Honda Pioneer 700 Deluxe have?
The 2025 Honda Pioneer 700 Deluxe is equipped with Dual Hydraulic Disc front brakes.
What type of rear brakes does the 2025 Honda Pioneer 700 Deluxe have?
The 2025 Honda Pioneer 700 Deluxe is equipped with Hydraulic Disc rear brakes.
