Transmission | Automatic PVT P/R/N/L/H In-line Shifting |
Chain Type | #520 Chain; 16T/45T |
Clutch | Wet, multi-plate |
Gear Ratios 1st | 9.403 : 1 |
Gear Ratios 2nd | 6.411 : 1 |
Gear Ratios 3rd | 4.763 : 1 |
Gear Ratios 4th | 3.796 : 1 |
Gear Ratios 5th | 3.243 : 1 |
Gear Ratios 6th | 2.789 : 1 |
Front Suspension | Sealed High Clearance Arched Dual A-Arm |
Rear Suspension | Sealed High Clearance Arched Dual A-Arm, Rolled IRS |
Front Travel | 16 in (406 mm) |
Rear Travel | 18 in (457 mm) |
Front Shocks | 2" Walker Evans Needle Shocks with 16-Position Adjustable Clickers |
Rear Shocks | 2.5" Walker Evans Needle Shocks with 16-Position Adjustable Clickers |
Front Braking System | Single Lever 3-Wheel Hydraulic Disc with Hydraulic Rear Foot Brake |
Rear Braking System | Single Lever 3-Wheel Hydraulic Disc with Hydraulic Rear Foot Brake |
Parking Brake | Park In-Transmission / Lockable Hand Lever |
Wheels | 14 in. (35.6 cm) Aluminum |
Front Tire | 27 X 9 Pro Armor X-Terrain |
Rear Tire | 27 X 11 Pro Armor X-Terrain |
Front Wheel | Machine Highlighted Cast Black 19 in x 3.5 in |
Rear Wheel | Machine Highlighted Cast Black 16 in x 5 in |
Wheelbase | 53 in (1,346 mm) |
Ground Clearance | 12 in (305 mm) |
Bed Box Dimensions | 28 x 22 x 7 in (72.0 x 57.0 x 17.8 cm) |
Overall Vehicle Size | 30.8" w x 42.7" h |
Seat Height | 37 in (940 mm) |
Rake / Trail | 25° / 3.9" |
Cargo System | Lock & Ride, 4 Gal (15 L) Front Dry Storage 2 Gal (8 L) Rear Storage |
Payload Capacity | 261 lbs (575 kg) |
Fuel Capacity | 5.25 gal (19.9 L) |
Box Capacity | 300 lb (136 kg) |
Hitch Type | Standard 1.25 in (3.2 cm) Receiver |
Hitch Capacity | 1,500 lb (680 kg) |
Rack Capacity (Front) | 120 lb (55 kg) |
Rack Capacity (Rear) | 240 lb (110 kg) |
Dry Weight | 864 lbs (392 kg) |
Gauges | Speedometer, Tachometer, Odometer, Fuel Gauge, Compass, Ambient Temperature, Gear Indicator |
Features | Other Standard: 3,500 lb. Polaris HD Winch with Synthetic Rope, Front Ultimate Series Bumper, Rear Ultimate Series Bumper, Cut and Sew Seat, In Pod Battery Charge Port, Painted Plastics, Painted Springs, PIN Activated Security System (P.A.S.S.), Fender Flares, 6 Moveable Tie-Down Points |
Lighting | LED POD, LED Bumper Lights, Dual LED Brake lights/Taillights |
Instrumentation | All Digital Gauge, Speedometer, Odometer, Tachometer, Two Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, AWD Indicator, Volt Meter, Coolant Temperature, Hi-Temp Light, Clock, DC Outlet |
Warranty | Duration: Transferable, one year included, unlimited-mileage limited warranty |
