Drivetrain
| Transmission | Shaft drive (cardan) |
| Clutch | |
| Gearbox | 5-speed |
| Transmission Type | Shaft drive (cardan) |
Suspension
| Front Suspension | 41mm fork |
| Rear Suspension | Dual shocks with five-position spring-preload adjustability |
| Front Travel | 4 in (102 mm) |
| Rear Travel | 4 in (102 mm) |
Brakes
| Front Braking System | Single disc. Two-piston calipers. |
| Rear Braking System | Single disc |
Tires
| Wheels | Cast aluminium |
| Front Tire | 120/70-ZR17 |
| Rear Tire | 180/55-ZR17 |
Dimensions
| Overall Vehicle Size | 29.2" w x 45.1" h |
| Rake / Trail | 24° / 4" |
| Wheelbase | 54.1 in (1,374 mm) |
| Seat Height | 25.6 in |
| Ground Clearance | 5.3 in (135 mm) |
Capacities
| Hitch Type | Rear: Receiver |
| Seating Capacity | 0 |
| Fuel Capacity | 4.5 gal (17 L) |
Weights
| Dry Weight | 553 lbs |
Lights & Safety
| Lighting | High beam, running lights, front fender light, directional light bar, neutral, low oil pressure, engine diagnostics, turn signals, security system (optional), 6-speed, low fuel warning, cruise control (optional), ABS (optional) |
| Instrumentation | Fairing-mounted electronic speedometer with odometer time-of-day clock on CD player/stereo dual trip meter low fuel indicator light and mileage countdown feature low oil pressure indicator light engine diagnostics readout LED indicator lights 6-speed indicator light Tachometer with fuel, voltage, oil pressure and ambient air temperature gauges |
| Warranty | One year. Transferable. Unlimited-mileage. |
What type of fuel does a 2024 Honda Shadow Phantom ABS use?
A 2024 Honda Shadow Phantom ABS uses Gasoline with fuel tank capacity up to 4 gallons.
What is the 2024 Honda Shadow Phantom ABS fuel capacity?
A 2024 Honda Shadow Phantom ABS has the fuel capacity of 4 gallons.
What transmission does the 2024 Honda Shadow Phantom ABS have?
The 2024 Honda Shadow Phantom ABS has a Shaft drive (cardan) transmission.
What engine does the 2024 Honda Shadow Phantom ABS have?
The 2024 Honda Shadow Phantom ABS is equipped with a 745cc 4-stroke V2 engine.
What is the wheelbase of the 2024 Honda Shadow Phantom ABS?
The 2024 Honda Shadow Phantom ABS has a wheelbase of 64.6.
What type of engine does the 2024 Honda Shadow Phantom ABS have?
The 2024 Honda Shadow Phantom ABS is equipped with a 4-stroke engine.
How is the 2024 Honda Shadow Phantom ABS cooled?
The 2024 Honda Shadow Phantom ABS is cooled by Liquid.
What type of fuel system does the 2024 Honda Shadow Phantom ABS have?
The 2024 Honda Shadow Phantom ABS is equipped with an Injection. PGM-FI with automatic enrichment circuit, one 34mm throttle body fuel system.
What type of starter does the 2024 Honda Shadow Phantom ABS have?
The 2024 Honda Shadow Phantom ABS is equipped with an Electric starter.
What is the 2024 Honda Shadow Phantom ABS compression ratio?
The 2024 Honda Shadow Phantom ABS has a compression ratio of 9.6:1.
What type of front brakes does the 2024 Honda Shadow Phantom ABS have?
The 2024 Honda Shadow Phantom ABS is equipped with Single disc. Two-piston calipers. front brakes.
What type of rear brakes does the 2024 Honda Shadow Phantom ABS have?
The 2024 Honda Shadow Phantom ABS is equipped with Single disc rear brakes.
