Transmission | Gen 2 Automatic PVT H/L/N/R/P; Shaft |
Clutch | Multi-plate with diaphragm spring in oil bath |
Gearbox | 6-speed |
Chain Type | 2.276:1 |
Gear Ratios 1st | 2.769:1 |
Gear Ratios 2nd | 1.882:1 |
Gear Ratios 3rd | 1.500:1 |
Gear Ratios 4th | 1.273:1 |
Gear Ratios 5th | 1.125:1 |
Gear Ratios 6th | 0.966:1 |
Transmission Type | Six-speed automatic Dual-Clutch Transmission (DCT) |
Front Travel | 8.5 in (216 mm) |
Rear Travel | 9.1 in (231 mm) |
Front Suspension | Independent Double Wishbone |
Rear Suspension | Independent |
Front Shocks | Front:FOX 2.5 PODIUM RC2 Piggyback with bypass, dual-speed compression and rebound adjustments/ Rear: FOX 3.0 PODIUM RC2 with bypass, dual-speed compression and rebound adjustments |
Rear Shocks | FOX 3.0 PODIUM RC2 with bypass, dual-speed compression and rebound adjustments |
Front Braking System | Dual Hydraulic Disc |
Rear Braking System | Dual Hydraulic Disc |
Parking Brake | Park In-Transmission |
Front Tire | 29 x 9-14; PRO ARMOR X-TERRAIN | Tire Ply Rating: 8-Ply Rated |
Rear Tire | 29 x 11-14; PRO ARMOR X-TERRAIN | Tire Ply Rating: 8-Ply Rated |
Front Wheel | Cast 8-Spoke 19" x 3.5" |
Rear Wheel | Cast 8-Spoke 16" x 3.5" |
Wheels | Aluminum |
Rake / Trail | 26° / 7" |
Wheelbase | 113 in (2,870 mm) |
Seat Height | 38 in (967 mm) |
Ground Clearance | 14 in (360 mm) |
Overall Vehicle Size | 68.1" w x 133.7" l x 76.2" h |
Bed Box Dimensions | 36.75 x 54.25 x 12.5 in (93 x 138 x 32 cm) |
Lean Angle (Left) | 33 |
Lean Angle (Right) | 33 |
Fuel Capacity | 11.5 gal (43.5 L) |
Seating Capacity | 0 |
Storage Capacity | 2.5 gal (9.4 L) |
Towing Capacity | 2,041 lbs (4,500 kg) |
Rack Capacity | 200 lb (91 kg) with LinQ quick-attach |
Hitch Type | Standard 2 in (5 cm) Receiver |
Hitch Capacity | 2,500 lb (1,134 kg) |
Cargo System | Lock & Ride |
Payload Capacity | 726 lbs (1,600 kg) |
Bed Capacity | 1,500 lbs. (680 kg) |
Box Capacity | 1000 lbs (454 kg) |
Cargo Capacity | 204 lbs (449 kg) |
Rack Capacity (Front) | 120 lb (54.4 kg) |
Rack Capacity (Rear) | 240 lb (109 kg) |
Dry Weight | 1,953 lbs (886 kg) |
Gauges | 7.6 in. wide digital display with keypad |
Magneto | 850-W |
Audio System | Includes 4 Standard 50 watt speakers. 2 in the fairing, 2 in the trunk. 200 watts total. |
Warranty | 6 / Limited |
Features | Water Fording Height: Equal to the Floorboards | Other Standard: Front Bumper with Integrated Winch, Plow & LED Mounts, Premium Cut & Sew Seats with Contoured Seatbacks and Embroidered Polaris Branding, Polaris HD 4500 lb Synthetic Rope Winch with Autostop and Wireless Remote, Factory-Installed Poly Sport Roof, Single Latch Cab Nets, Polaris Pulse Electrical System (6 position), 12V Accessory Outlet, Battery Trickle-Charging Outlet, USB Outlet |
Lighting | Dual LED Headlights, 1250lm Low Beam, 2300lm High Beam, Dual LED Tail Lights |
Steering | Tilt: Standard |
Instrumentation | Dual-sweep Analog Dials w/ 4" LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder, 2 DC Outlets, USB Charge Port, Automatic Speed Limiting in 2 mph increments starting at 16 mph to max speed. |
Cage Type | Dual-phase 980 steel |
Handlebars | Aluminum |
