| Chain Type | 2.379:1 |
| Clutch | Multiplate wet |
| Gear Ratios 1st | 10.169:1 |
| Gear Ratios 2nd | 6.933:1 |
| Gear Ratios 3rd | 5.151:1 |
| Gear Ratios 4th | 4.105:1 |
| Gear Ratios 5th | 3.508:1 |
| Gear Ratios 6th | 3.017:1 |
| Transmission | Chain (final drive) |
| Gearbox | 5-speed |
| Transmission Type | Chain (final drive) |
| Front Suspension | Kayaba Ø 41 mm USD with top out spring. Rebound, compression and spring pre-load adjustment. |
| Rear Suspension | Asymmetrical aluminium rear arm. Rear shock absorber with top-out spring. Adjustable preload and rebound. |
| Front Shocks | FOX 2.5 PODIUM RC2 Piggyback with bypass, dual speed compression and rebound adjustments |
| Rear Shocks | FOX 3.0 PODIUM RC2 Piggyback with bypass, dual-speed compression and rebound adjustments |
| Front Travel | 4.3 in (110 mm) |
| Rear Travel | 5.1 in (130 mm) |
| Front Braking System | Single disc. Hydraulic. Two-piston calipers. Optional ABS. |
| Rear Braking System | Single disc. Hydraulic. Single-piston caliper. Optional ABS. |
| Front Wheel | 10-Spoke Machined Cast 19" x 3.5" |
| Rear Wheel | 10-Spoke Machined Cast 16" x 5" |
| Front Tire | 120/70-ZR17 |
| Rear Tire | 180/55-ZR17 |
| Wheels | Aluminium alloy wheel. |
| Overall Vehicle Size | 28.7" w x 44.2" h |
| Rake / Trail | 105° / 4" |
| Wheelbase | 53.9 in (1,370 mm) |
| Seat Height | 30 in |
| Ground Clearance | 14.1 in (359 mm) |
| Lean Angle (Left) | 33 |
| Lean Angle (Right) | 33 |
| Fuel Capacity | 4 gal (15 L) |
| Storage Capacity | 2.1 gal (8.1 L) |
| Rack Capacity | 200 lb (90 kg) |
| Dry Weight | 224 lbs |
| Gauges | Fairing-mounted instrument cluster featuring analog speedometer and tachometer with fuel gauge, range, odometer and current gear. 15 LED telltale indicators: cruise control enabled, cruise control set, neutral, high beam, turn signal, ABS, check engine, low tire pressure, battery, low fuel, security system, low engine oil pressure and MPH or km/h unit designation. |
| Magneto | 1700-W |
| Features | A 7" Display Powered by RIDE COMMAND with Turn-by-Turn GPS Navigation, Customizable Gauge Screens, Bluetooth Connectivity, AM/FM Radio, Selectable Ride Modes, and More; Factory-Installed RIDE COMMAND+ Telecommunications Unit (TCU) for One-Year FREE Provides Live Weather and Traffic Overlays, Apple CarPlay, Bike Health, Bike Locator, Intuitive Destination Search, and More |
| Lighting | Triple LED headlights and daytime running lights |
| Warranty | One year. Unlimited milage. Transferable. |
| Steering | Power: Gen 2 Tri-mode DPS High torque |
| Cage Type | High strength (Dual phase) steel tubing and stampings |
| Instrumentation | USB A (charging port & communication port) DC outlet (10-A) |
