Clutch | |
Gearbox | 5-speed |
Transmission | manual |
Transmission Type | Belt |
Chain Type | #520 Chain; 16T/45T |
Gear Ratios 1st | 2.769:1 |
Gear Ratios 2nd | 1.882:1 |
Gear Ratios 3rd | 1.500:1 |
Gear Ratios 4th | 1.273:1 |
Gear Ratios 5th | 1.125:1 |
Gear Ratios 6th | 0.966:1 |
Front Travel | 16 in (406 mm) |
Rear Travel | 18 in (457 mm) |
Front Suspension | 41mm Hydraulic Telescopic Fork |
Rear Suspension | Single Shock |
Front Shocks | Walker Evans Velocity Series Shocks |
Rear Shocks | Walker Evans Velocity Series Shocks |
Front Braking System | Single disc |
Rear Braking System | Single disc |
Parking Brake | Park In-Transmission |
Front Tire | 30 x 10-15; Pro Armor Crawler XGF or ITP Ultra Cross R Spec |
Rear Tire | 30 x 10-15; Pro Armor Crawler XG or ITP Ultra Cross R Spec |
Wheels | 15" Aluminum |
Front Wheel | Cast 8-Spoke 16" x 3.5" |
Rear Wheel | Cast 8-Spoke 16" x 3.5" |
Overall Vehicle Size | 64" w x 133.3" l x 77.6" h |
Rake / Trail | 25° / 3.9" |
Wheelbase | 115 in (2,920 mm) |
Seat Height | 37 in (940 mm) |
Ground Clearance | 13.5 in (343 mm) |
Bed Box Dimensions | 27.5 x 43.1 x 11.6" (69.8 x 109 x 29.5 cm) |
Lean Angle (Left) | 31 |
Lean Angle (Right) | 31 |
Fuel Capacity | 9.5 gal (35.9 L) |
Seating Capacity | 0 |
Cargo System | Lock & Ride |
Payload Capacity | 580 lbs (1,280 kg) |
Box Capacity | 600 lb (272 kg) Rear Dumping Box |
Bed Capacity | 500 lb (226.8 kg) |
Hitch Type | Standard 2 in (5 cm) Receiver |
Cargo Capacity | 454 lbs (1,000 kg) |
Storage Capacity | 2.5 gal (9.4 L) |
Towing Capacity | 1,134 lbs (2,500 kg) |
Hitch Capacity | 1,500 lb (680 kg) |
Rack Capacity (Front) | 120 lb (55 kg) |
Rack Capacity (Rear) | 240 lb (110 kg) |
Rack Capacity | 200 lb (91 kg) with LinQ quick-attach |
Dry Weight | 1,832.4 lbs |
Gauges | B1 |
Audio System | Upgraded PowerBand 2.0 Audio package Includes: 2 - 100 watt fairing speakers, 2 - 100 watt saddlebag speakers. 400 watts total. |
Magneto | 850 W |
Warranty | |
Steering | Tilt Steering: Standard |
Features | Ingress / Egress: Half Doors Standard | Other Standard: POLARIS HD 4500 LB Winch w/ Synthetic Rope, Aluminum Fairlead, Rubber Isolator, AutoStop & Plow Mode. Sport Low Profile Front Bumper ProFit Sport Roof Rockford Fosgate Stage 3 Audio |
Lighting | LED Headlight w/ Accent & LED Taillights |
Instrumentation | Dual-sweep Analog Dials w/ 4" LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder Light, Gear Indicator, DC Outlet RIDE COMMAND 7 Glove-Touch Display: Digital Instrumentation, Built-In GPS, Mapping, Vehicle-to-Vehicle w/ Group Ride, Follow the Leader, & Messenging. Front & Rear On-board Cameras. Bluetooth & USB Smartphone Connectivity, AM/FM & Weather Radio, & In-Vehicle Communications Capable. ROCKFORD FOSGATE Stage 3 Audio: (2) 6.5" 50W Front Co-axial Speakers & (2) 6.5" 50W Rear Co-axial Speakers, 4-Channel Amp w/ Fade, Automatic Volume Level, & 5-band Equalizer |
Cage Type | Dual-phase 980 steel |
Handlebars | Neken, aluminium 28/22 mm |
Headlight Type | LED |
