Drivetrain
| Transmission | |
| Clutch | Wet, Multi-Plate, Assist |
| Gearbox | 6-speed |
| Transmission Type | Six-speed automatic Dual-Clutch Transmission (DCT) |
| Chain Type | 2.2 : 1 |
| Gear Ratios 1st | 9.403 : 1 |
| Gear Ratios 2nd | 6.411 : 1 |
| Gear Ratios 3rd | 4.763 : 1 |
| Gear Ratios 4th | 3.796 : 1 |
| Gear Ratios 5th | 3.243 : 1 |
| Gear Ratios 6th | 2.789 : 1 |
Suspension
| Front Suspension | Independent Double Wishbone |
| Rear Suspension | Independent Double Wishbone |
| Front Shocks | Walker Evans 2.5 Velocity Needle Shock with 16-Position Adjustable Clickers |
| Rear Shocks | Walker Evans 3.0 Velocity Needle Shock with 16-Position Adjustable Clickers |
| Front Travel | 5.1 in (130 mm) |
| Rear Travel | 4.9 in (124 mm) |
Brakes
| Front Braking System | Hydraulic Disc |
| Rear Braking System | Hydraulic Disc |
| Parking Brake | Park In-Transmission |
Tires
| Front Wheel | 10-Spoke Contrast Cut 19 in x 3.5 in |
| Rear Wheel | 10-Spoke Contrast Cut 16 in x 5 in |
| Front Tire | 32 x 10-15 Maxxis Rampage Fury; 8-Ply Rated; Wheel Size 15x7 |
| Rear Tire | 32 x 10-15 Maxxis Rampage Fury; 8-Ply Rated; Wheel Size 15x7 |
| Wheels | 15" Cast Aluminum Rim with 5-Lug Pattern |
Dimensions
| Overall Vehicle Size | 63" w x 117.1" l x 76.9" h |
| Wheelbase | 125 in (3,175 mm) |
| Seat Height | 27 in (686 mm) |
| Ground Clearance | 16 in (406 mm) |
| Rake / Trail | 25° / 5.9" |
| Lean Angle (Left) | 31 |
| Lean Angle (Right) | 31 |
| Bed Box Dimensions | 26 x 17.7 x 11.5 in (66 x 45 x 29.2 cm) |
Capacities
| Cargo Capacity | 272 lbs (600 kg) |
| Storage Capacity | 7.3 gal (27.6 L) |
| Fuel Capacity | 12 gal (45.4 L) |
| Towing Capacity | 907 lbs (2,000 kg) |
| Bed Capacity | 1,500 lbs. (680 kg) |
| Hitch Type | Standard 1.25 in (3.2 cm) Receiver |
| Payload Capacity | 331 lbs (730 kg) |
| Seating Capacity | 2 |
| Hitch Capacity | 1,500 lb (680 kg) |
| Cargo System | Lock & Ride Fold Flat Rear Storage, convertible rear seat storage with integrated tie down points, 27.7 x 52.8 x 19.5 in (70.4 x 134.1 x 49.53 cm) |
| Rack Capacity (Front) | 120 lb (55 kg) |
| Rack Capacity (Rear) | 240 lb (110 kg) |
| Box Capacity | 300 lb (136 kg) |
| Rack Capacity | 200 lb (91 kg) with LinQ quick-attach |
Weights
| Dry Weight | 2,409 lbs (1,093 kg) |
Electronics
| Gauges | Fairing-Mounted Instrument Cluster with Analog Speedometer and Tachometer; Fuel Gauge, Range, Odometer and Current Gear |
| Magneto | 650-W |
| Audio System | Includes 2 Standard 50 watt fairing speakers, 100 watts total. |
Lights & Safety
| Warranty | 12 / Limited |
| Features | Doors: Vented Full Doors | Other Standard: High Output 900W Charging System with Sealed Electrical, Polaris Pulse System, In-Dash Charge Port, Polaris P.A.S.S. |
| Instrumentation | RIDE COMMAND 7 Glove-Touch Display: DYNAMIX 2.0 Visualizer, Built-In GPS, Group ride (cell-based or GPS based), Topographic Mapping, Bluetooth & USB Smartphone Connectivity, AM/FM & Weather Radio, In-Vehicle Communications Capable With Optional Sena Headsets, Polaris P.A.S.S Anti-Theft System. Dual-sweep Analog Dials w/ 4" LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals. Digital Instrumentation: Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder Light, Gear Indicator, DC Outlet |
| Steering | Power: Rack Mounted High Assist Electronic Power Steering with Quick Turn Rack; Race Inspired Steering Wheel with Tilt & Telescoping Adjustment; RIDE COMMAND Push Button Controls |
| Cage Type | Profiled cage, ROPS approved |
| Lighting | Signature Animated RZR Fang Accent Lighting; White LED, Low / High & Red LED Tail / Brake Lights; Interior Dash Accent Lighting |
| Headlight Type | LED |
Frequently asked questions about 2025 Honda Pioneer 1000
What type of fuel does a 2025 Honda Pioneer 1000 use?
A 2025 Honda Pioneer 1000 uses Gasoline.
What is the 2025 Honda Pioneer 1000 fuel capacity?
A 2025 Honda Pioneer 1000 has the fuel capacity of 8 gallons.
What type of engine does the 2025 Honda Pioneer 1000 have?
The 2025 Honda Pioneer 1000 is equipped with a 4-stroke engine.
How is the 2025 Honda Pioneer 1000 cooled?
The 2025 Honda Pioneer 1000 is cooled by Liquid.
What type of fuel system does the 2025 Honda Pioneer 1000 have?
The 2025 Honda Pioneer 1000 is equipped with a Fuel Injection fuel system.
What type of starter does the 2025 Honda Pioneer 1000 have?
The 2025 Honda Pioneer 1000 is equipped with a Electric starter.
What is the 2025 Honda Pioneer 1000 compression ratio?
The 2025 Honda Pioneer 1000 has a compression ratio of 10:1.
What type of front brakes does the 2025 Honda Pioneer 1000 have?
The 2025 Honda Pioneer 1000 is equipped with Hydraulic Disc front brakes.
What type of rear brakes does the 2025 Honda Pioneer 1000 have?
The 2025 Honda Pioneer 1000 is equipped with Hydraulic Disc rear brakes.
$16,599
Estimated Payment
$245 / month
Personalize payment
On sale now!
| MSRP | $17,599 |
| Dealer discount | -$1,000 |
| Dell's price | $16,599 |
