Drivetrain
| Transmission | Shaft drive (cardan) |
| Gearbox | 5-speed |
| Clutch | |
| Transmission Type | Shaft drive (cardan) |
Suspension
| Front Suspension | 41mm fork |
| Rear Suspension | Dual shocks with five-position spring-preload adjustability |
| Front Travel | 4.6 in (117 mm) |
| Rear Travel | 2.9 in (74 mm) |
Brakes
| Front Braking System | Single disc. Two-piston calipers. |
| Rear Braking System | Single disc |
Tires
| Wheels | Silver, Bullet Hole Disc Cast Aluminum |
| Front Tire | 140/75-R17 |
| Rear Tire | 200/55-R17 |
Dimensions
| Overall Vehicle Size | 36.4" w x 56.4" h |
| Rake / Trail | 31° / 6" |
| Wheelbase | 64.5 in (1,638 mm) |
| Seat Height | 25.6 in |
| Ground Clearance | 5.1 in (130 mm) |
Capacities
| Fuel Capacity | 5 gal (18.9 L) |
| Seating Capacity | 3 |
| Hitch Type | Rear: Receiver |
Weights
| Dry Weight | 543 lbs |
Lights & Safety
| Warranty | One year. Transferable. Unlimited-mileage. |
| Lighting | High beam, neutral, low oil pressure, turn signals, engine diagnostics, security system (optional), 6-speed, low fuel warnings |
| Instrumentation | Tank-mounted electronic speedometer with odometer, time-of-day clock on odometer, dual tripmeter, RPM/gear display, fuel gauge with low fuel warning light and countdown feature, low oil pressure indicator light, engine diagnostics readout, LED indicator lights, 6-speed indicator light |
What type of fuel does a 2024 Honda Shadow Phantom use?
A 2024 Honda Shadow Phantom uses Gasoline with fuel tank capacity up to 4 gallons.
What is the 2024 Honda Shadow Phantom fuel capacity?
A 2024 Honda Shadow Phantom has the fuel capacity of 4 gallons.
What transmission does the 2024 Honda Shadow Phantom have?
The 2024 Honda Shadow Phantom has a Shaft drive (cardan) transmission.
What engine does the 2024 Honda Shadow Phantom have?
The 2024 Honda Shadow Phantom is equipped with a 745cc 4-stroke V2 engine.
What is the wheelbase of the 2024 Honda Shadow Phantom?
The 2024 Honda Shadow Phantom has a wheelbase of 64.6.
What type of engine does the 2024 Honda Shadow Phantom have?
The 2024 Honda Shadow Phantom is equipped with a 4-stroke engine.
How is the 2024 Honda Shadow Phantom cooled?
The 2024 Honda Shadow Phantom is cooled by Liquid.
What type of fuel system does the 2024 Honda Shadow Phantom have?
The 2024 Honda Shadow Phantom is equipped with an Injection. PGM-FI with automatic enrichment circuit, one 34mm throttle body fuel system.
What type of starter does the 2024 Honda Shadow Phantom have?
The 2024 Honda Shadow Phantom is equipped with an Electric starter.
What is the 2024 Honda Shadow Phantom compression ratio?
The 2024 Honda Shadow Phantom has a compression ratio of 9.6:1.
What type of front brakes does the 2024 Honda Shadow Phantom have?
The 2024 Honda Shadow Phantom is equipped with Single disc. Two-piston calipers. front brakes.
What type of rear brakes does the 2024 Honda Shadow Phantom have?
The 2024 Honda Shadow Phantom is equipped with Single disc rear brakes.
