Transmission | Chain (final drive) |
Chain Type | O-ring-sealed chain; 15T/41T |
Transmission Type | Chain (final drive) |
Clutch | Multi plate wet |
Gearbox | 6-speed |
Front Suspension | 49mm leading-axle inverted telescopic Showa coil-spring fork with rebound and compression damping adjustability |
Rear Suspension | Pro-Link Showa single shock with adjustable spring preload, rebound and compression damping adjustability |
Front Travel | 5.1 in (130 mm) |
Rear Travel | 5.2 in (132 mm) |
Front Braking System | Single disc. Hydraulic. Two-piston calipers. |
Rear Braking System | Single disc. Hydraulic. Single-piston caliper. |
Front Tire | 110/70-17 |
Rear Tire | 150/60-17 |
Wheels | Wire spoked |
Overall Vehicle Size | 32.6" w x 86.3" l x 50" h |
Rake / Trail | 24.7° / 4" |
Wheelbase | 52.3 in (1,328 mm) |
Seat Height | 37.2 in |
Ground Clearance | 5.1 in (130 mm) |
Fuel Capacity | 2.6 gal (9.84 L) |
Bed Capacity | 299 pounds |
Dry Weight | 289 lbs |
Warranty | One year. Transferable. Unlimited-mileage. |
