Transmission | Automatic PVT P/R/N/L/H |
Transmission Type | Chain (final drive) |
Clutch | |
Gearbox | 5-speed |
Chain Type | Direct rear driveshaft |
Gear Ratios 1st | 10.169:1 |
Gear Ratios 2nd | 6.933:1 |
Gear Ratios 3rd | 5.151:1 |
Gear Ratios 4th | 4.105:1 |
Gear Ratios 5th | 3.508:1 |
Gear Ratios 6th | 3.017:1 |
Front Suspension | Light Weight Boxed Dual A-Arm with 3 piece Stabilizer Bar and 27.0 in (68.6 cm) *Usable Travel, 22.25 in (56.5 cm) Wheel Travel, Unitized Hubs |
Rear Suspension | Boxed Trailing Arm with Toe Link, High-Clearance Radius Rods, and 3 Piece Stabilizer Bar and 29.0 in (73.7 cm) *Usable Travel, 24.5 in (62.2 cm) Wheel Travel, Unitized Hubs |
Front Travel | 7.3 in (185 mm) |
Rear Travel | 8.5 in (216 mm) |
Front Shocks | 2.5 in Walker Evans Velocity Needle Shock with 16-Position Adjustable Clickers |
Rear Shocks | 3.0 in Walker Evans Velocity Needle Shock with 16-Position Adjustable Clickers |
Front Braking System | 4-Wheel Hydraulic Disc with Triple-Bore |
Rear Braking System | 4-Wheel Hydraulic Disc Dual-Bore Rear Calipers |
Parking Brake | Park In-Transmission |
Wheels | 5-Lug, 15" Cast Aluminum Rim |
Front Tire | 32 x 10-15 Maxxis Rampage Fury; 8-Ply Rated; Wheel Size 15x7 |
Rear Tire | 32 x 10-15 Maxxis Rampage Fury; 8-Ply Rated; Wheel Size 15x7 |
Front Wheel | 10-Spoke Machined Cast 19 in x 3.5 in |
Rear Wheel | 10-Spoke Machined Cast 16 in x 5 in |
Overall Vehicle Size | 33" w x 85.9" l x 50.5" h |
Seat Height | 38 in |
Rake / Trail | 24° |
Wheelbase | 133.5 in (3,391 mm) |
Ground Clearance | 16 in (406 mm) |
Lean Angle (Left) | 31 |
Lean Angle (Right) | 31 |
Bed Box Dimensions | 29.5 x 23.8 x 8.1 in (75 x 60.5 x 20.6 cm) |
Fuel Capacity | 12.3 gal (46.56 L) |
Seating Capacity | 0 |
Cargo System | Lock & Ride; Convertible Fold Flat Rear Seat Storage with Integrated Tie Down Points, 27.7 x 52.8 x 19.5 in (70.4 x 134.1 x 49.53 cm) Factory Equipped Cargo Liner |
Payload Capacity | 408 lbs (900 kg) |
Rack Capacity (Front) | 33 pounds |
Rack Capacity (Rear) | 66 pounds |
Hitch Type | Standard 1.25 in (3.2 cm) Receiver |
Cargo Capacity | 454 lbs (1,000 kg) |
Storage Capacity | 10.4 gal (39.5 L) |
Towing Capacity | 1,134 lbs (2,500 kg) |
Hitch Capacity | 2,500 lb (1,134 kg) |
Box Capacity | 300 lb (136.1 kg) |
Rack Capacity | 200 lb (90 kg) |
Bed Capacity | 299 pounds |
Dry Weight | 2,441 lbs (1,107 kg) |
Gauges | 4.5 in. wide digital display |
Audio System | Includes 4 Standard 50 watt speakers. 2 in the fairing, 2 in the trunk. 200 watts total. |
Magneto | 650 W |
Warranty | |
Features | Doors: Vented Full Doors | Other Standard: High Output 900W Charging System with Sealed Electrical, Polaris Pulse System, In-Dash Charge Port, Polaris P.A.S.S. |
Lighting | Signature White LED, Low/High & Red LED Tail/Brake Lights |
Instrumentation | Dual-sweep Analog Dials w/ 4" LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder Light, Gear Indicator, Front and Rear DC Outlet, Polaris P.A.S.S Anti-Theft System |
Steering | Power: Rack Mounted High Assist Electronic Power Steering with Quick Turn Rack; Race Inspired Steering Wheel; Ride Command Push Button Controls |
Cage Type | Profiled cage, ROPS approved |
Handlebars | Tapered aluminum 28/22/18 mm |
